Technical Specifications
ASIC Chip: BM1370 (from Antminer S21 Pro)
Hashrate: ~1.1 TH/s
Power Consumption: ~18W
Connectivity: Wi-Fi for connectivity (2.4Ghz), USB-C for optional data access & debugging
Display: 0.91-inch SSD1306 OLED I2C display
Cooling: 40x40x20mm Gelid 5V PWM 7500RPM premium fan
Firmware: Open-source AxeOS with web-based GUI
Technical Specifications
ASIC Chip: BM1370 (from Antminer S21 Pro)
Hashrate: ~6 TH/s
Power Consumption: ~100W
Connectivity: Wi-Fi for connectivity (2.4Ghz) , USB-C for optional data access & debugging
Display: 1.9-inch LILYGO T-Display S3 LCD color screen
Cooling: Thermalright AXP90 X36 Low Profile cooler
Firmware: Open-source AxeOS with web-based GUI


Technical Specifications
ASIC Chip: BM1370 (from Antminer S21 Pro)
Hashrate: ~9.6 TH/s
Power Consumption: ~180W
Connectivity: Wi-Fi for connectivity (2.4Ghz), USB-C for optional data access & debugging
Display: 1.9-inch LILYGO T-Display S3 LCD color screen
Cooling: 2 x Thermalright AXP90 X53 Black Low Profile coolers
Firmware: Open-source with web-based GUI


Technical Specifications
Algorithm: SHA-256 (Bitcoin)
Hashrate: 6 TH/s
Power Consumption: 140 W (28 V, 5 A)
Efficiency: ~23.3 J/TH
Noise Level: ~33–40 dB
Dimensions: 205 × 115 × 58.5 mm
Weight: ~0.86 kg
Connectivity: Wi-Fi (USB adapter included), Ethernet (via USB adapter)
Cooling: Air-cooled (3 built-in fans)
Performance and Design
High Hashrate
The Avalon Q produces up to 90 TH/s of Bitcoin SHA-256 hashing power, positioning it well above entry-level miners and closer to a balanced home or small-farm machine.Power Consumption
Operating power is approximately 1,674 W, reflecting its higher performance class and requiring appropriate power delivery and cooling.Air-Cooled
The miner uses an integrated air-cooling system to manage heat during continuous operation, with noise levels ranging from 45 to 65dB.




Technical Specifications
ASIC Chip: BM1370 (from Antminer S21 Pro)
Hashrate: ~4.8 TH/s
Power Consumption: ~80W
Connectivity: Wi-Fi for connectivity (2.4Ghz) , USB-C for optional data access & debugging
Display: 1.9-inch LILYGO T-Display S3 LCD color screen
Cooling: Thermalright AXP90 X36 Low Profile cooler
Firmware: Open-source AxeOS with web-based GUI
